The Raymarine Magnum 4kW Pedestal (E70484) from Nomadic Supply Company® is the open-array radar pedestal and VCM100 voltage converter module for the Magnum 4kW radar system, delivering long-range X-band magnetron performance trusted by the United States Coast Guard and offshore sport fishing captains.
Raymarine Magnum 4kW Pedestal (E70484) Features:
- Long-Range X-Band Performance. Delivers 4kW magnetron radar performance with a maximum range of up to 72 nautical miles — trusted by the U.S. Coast Guard and competitive sport fishing captains for consistent target detection and reliability in all conditions.
- Superior Bird Mode. Advanced Bird Mode automatically optimizes the radar image to target sea birds with greater clarity up to 10nm, helping anglers locate flocks — and the schooling baitfish below — faster and with less fuel consumption.
- Enhanced Radar Imaging. Raymarine beam sharpening technology delivers better than 1-degree bearing resolution for more detailed target separation, map-like coastal detail, and superior long-range performance across all range scales.
- Best-in-Class Target Tracking. Fully automatic MARPA target acquisition and tracking, combined with Evolution 9-axis heading sensor technology, delivers real-time, accurate target plots for superior situational awareness.
- True Trails. True Trails target history displays a historical “wake” behind every moving contact, making it easier to interpret vessel motion and make smart maneuvering decisions.
- Real-Time Heading Updates. Connect with Axiom and LightHouse OS for uninterrupted radar imagery during course changes — the radar display rotates freely without needing to refresh the entire screen.
- Broad Chartplotter Compatibility. Compatible with Axiom 2, Axiom+, Axiom Pro, and legacy Raymarine MFDs including LightHouse 2-based a/c/e/eS/gS-Series, C-Series Widescreen, E-Series Widescreen, and E-Series Classic chartplotters.
Raymarine Magnum 4kW Pedestal (E70484) Includes:
- 1x Raymarine Magnum 4kW Pedestal (E70484)
- 1x VCM100 Voltage Converter Module
- 1x 15m RayNet Radar & Power Cable
- Mounting hardware kit
Raymarine Magnum 4kW Pedestal (E70484) Specifications:
- Peak Power Output: 4 kW
- Maximum Range: 72 nautical miles
- Transmit Frequency: 9405 MHz ±20 MHz
- Beamwidth (Vertical): 25° (nominal)
- Rotation Speed: 24 / 48 RPM
- Warm-Up Time: 75 seconds
- Standby to Transmit: 2.5 seconds
- Power Consumption (Typical): <70 W
- Power Consumption (Standby): <30 W
- Power Consumption (Sleep): <1.2 W
- Waterproof Rating: IPx6
- Max Wind Speed: 85 knots
- Operating Temperature: -25°C to +55°C (-13°F to +131°F)
- Pedestal Dimensions: H 430 mm (16.9 in) × L 409 mm (16.1 in) × W 314 mm (12.3 in)
- Weight: 29 kg (63.93 lbs)
Raymarine Magnum 4kW Pedestal Documents:
Raymarine Magnum 4kW Pedestal Installation Guide
