49519, Amana Carbide Tipped Corner Round 5/8 Radius x 1-3/4 Dia x 7/8 x 1/2 Inch Shank
The basic edge-forming bit, the corner-rounding bit rounds an edge to a given radius. The tool is shouldered to cut a fillet. The cut can be used to ease edges, as a simple profile, or as a part of a complex one. Also known as roundover, rounding over and quarter-round. If a smaller pilot bearing is used, a second shoulder can be produced, in effect making the bit a beading bit. Maximum RPM 28,000.
Specifications:
- Tool No. 49519
- Diameter (D) 1-3/4
- Radius (R) 5/8
- Cutting Height (B) 7/8
- Shank (d) 1/2
- Overall Length (L) 2-3/4
- Replacement Bearing 47706
- Flutes 2
