49612, Amana Carbide Tipped Beading 3/8 Radius x 1-1/4 Dia x 5/8 x 1/4 Inch Shank
Cut a quarter-round shape bounded by fillets, known as a bead, in one pass by this bit. The width of one fillet is set by the pilot bearing size, while the other is controlled by the depth of cut. A beading bit can be transformed into a corner rounding bit by changing the bearing (& vice versa).
Specifications:
- Tool No. 49612
- Diameter (D) 1-1/4
- Radius (R) 3/8
- Cutting Height (B) 5/8
- Shank (d) 1/4
- Overall Length (L) 2-3/16
- Replacement Bearing 47702
- Flutes 2
